32
Figure 27. Fiber Connected Switch Results
You can save the current measurement data the tester has collected
into a report that can be viewed and printed through the LinkRunner
Manager PC application. This information includes:
• AutoTest results
• Switch results
• Cable test results
Note
The LR-AT 1000 model can save up to 10 reports. The LR-AT
2000 model can save up to 50 reports.
Link-Live Cloud Service automatically uploads the results from
AutoTest only.
To save the measurement data collected on the tester:
1 Press P. The tester shows a default filename at the bottom of
the screen.
• To save the data with the filename shown, press Save.
The tester saves the data into a report file.
• To overwrite a report that is saved on the tester, highlight
the report, press L, press Save, then press OK.
• To change the filename, press Edit.
Note
Report names can have a maximum of 12 characters. The
extension LRS is appended when the file is saved to your PC
through the LinkRunner Manager PC application.
• To delete characters in the filename, press Backspace.
• To add characters to the filename, use to highlight
a character, then press L.
• To move the cursor in the filename, highlight the filename,
then press .
