12
Tools lets you manage files and settings.
Link established indicator.
Displays the link speed and duplex mode.
Displays the connection type: PoE , 802.1x , fiber . For 802.1x, a green lock indicates authentication
passed, yellow indicates it is not needed, and a red
closed lock indicates it failed authentication.
* IntelliTone is a trademark of Fluke Networks.
IV. COMMON QUESTIONS LINKRUNNER AT
CAN ANSWER
First, connect an RJ-45 or fiber cable (2000 model only) from the
network hub or wall plate to the LinkRunner AT RJ-45 LAN or fiber
port. Check the following list of questions and associated answers to
see how LinkRunner AT can help you get the job done.
Is this a good RJ-45 Ethernet cable?
Use Cable testing and the built in wiremap for patch cables, or an
external WireView
TM
Office Locator.
Am I receiving a good fiber signal?
Connect to your network via a SFP adapter and validate the signal
strength and link in the Switch screen.
Where does this RJ-45 cable go?
Use the Cable test toner function, Switch > Flash Port function, or
Switch discovery protocol.
Is this cable hooked up to anything?
Select Switch to identify an open cable, an active link, or an un-
powered network device.
Common Questions LinkRunner AT Can Answer
