UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
35
1-800-547-6547
Figure B
Clamp orientation
Figure A
Clamp orientation
transducer without
handle
5. Open the clamp by turning the clamp thumbscrews counterclockwise to fit
6. ucer head or handle.
Make sure that the transducer radiating head (or crystal) remains completely
submerged in the coupling water.
7. Re-center the transducer head directly over the middle of the transducer well
using the centering ring to assure alignment for accurate readings. Make
sure the transducer surface is entirely in the coupling medium. The
transducer head should be completely coupled with the distilled and
degassed water and there should be no bubbles beneath the radiating head of
the transducer. Any bubbles beneath the transducer head will create a low
reading.
ly
Damage
the desired transducer head or handle.
Tighten the clamp screw to effectively grab the transd
ā Caution
Do not ship the power meter with the transducer clamp assemb
mounted on the unit, or the cone and hanger still in the unit.
to the unit will result and the warranty will be void.
transducer with
handle
