Technical Specifications
The following table lists the technical specifications for the cable modem.
Table 4.Technical specifications
SpecificationFeature
• Input: 110–120V, 47–60 Hz
• Output: 12 VDC, 1.5A
Power adapter
• Dimensions (W x D x H): 2.5 x 4.9 x 7.6 in. (64 x 124 x 193
mm)
• Weight: 0.65 lb (0.30 kg)
Physical specifications
• Operating temperature: 32° to 104°F (0° to 40°C)
• Operating humidity: 90% maximum relative humidity,
noncondensing
Environmental
• Local: One 10/100/1000 RJ-45 Gigabit Ethernet port
• Voice: Two bridged RJ-11 phone ports
• Internet: Coaxial cable connector, DOCSIS 3.0; backward
compatible with DOCSIS 2.0
Interface
• 8 MB Flash
• 128 MB RAM
Memory
• 16 bonded downstream
• 4 bonded upstream
Channels
CableLabs certified for U.S. cable Internet services
Certifications
Technical Specifications
30
Voice Cable Modem
