NETGEAR CM500V User Manual

Table 1. LED descriptions (Continued)
• Green. A powered-on device is connected to the Ethernet
port at 1000 Mbps.
• Amber. A powered-on device is connected to the Ethernet
port at 10 Mbps or 100 Mbps.
• Off. No device is connected to the Ethernet port.
• Blinking green or amber.The Ethernet port is processing
traffic.
Ethernet
• Solid green.The Tel 1 or 2 port is online.
• Blinking green.The Tel 1 or 2 port is processing a call or the
phone is off-hook.
• Off.The Tel 1 or 2 port is not in use.
Tel 1 and 2
Rear Panel
The connections and button on the rear panel are shown in the following figure.
Figure 3. Rear panel
Viewed from top to bottom, the back panel contains the following components:
Hardware Setup
8
Voice Cable Modem

NETGEAR CM500V Specifications

General

Product color	Black
DC-in jack	Yes
Modem (RJ-11) ports	2
Ethernet LAN (RJ-45) ports	1
Cables included	LAN (RJ-45), Phone (RJ-11)
