Reference Manual for the ADSL Firewall Router DG834
7-26 Virtual Private Networking (Advanced Feature)
v2.0, September 2005
6. Repeat for the DG834 on LAN B and pay special attention to use the following network
settings as appropriate.
• WAN IP of the remote VPN gateway (e.g., 14.15.16.17)
• LAN IP settings of the remote VPN gateway:
— IP Address (e.g, 192.168.0.1)
— Subnet Mask (e.g., 255.255.255.0)
• Preshared Key (e.g., 12345678)
7. Use the VPN Status screen to activate the VPN tunnel by performing the following steps:
a. Open the DG834 management interface and click on VPN Status to get the VPN Status/
Log screen (Figure 7-28).
Note: The VPN Status screen is only one of three ways to active a VPN tunnel. See
“Activating a VPN Tunnel” on page 7-27 for information on the other ways.
Figure 7-28
