Reference Manual for the ADSL Firewall Router DG834
Virtual Private Networking (Advanced Feature) 7-45
v2.0, September 2005
5. Click Apply. The Get VPN Policies web page is displayed.
6. Repeat for the DG834 on LAN B and pay special attention to use the following network
settings as appropriate.
• General, Remote Address Data (e.g., 14.15.16.17)
• Remote LAN, Start IP Address
— IP Address (e.g, 192.168.0.1)
— Subnet Mask (e.g., 255.255.255.0)
— Preshared Key (e.g., 12345678)
7. Use the VPN Status screen to activate the VPN tunnel by performing the following steps:
Figure 7-45
Note: The VPN Status screen is only one of three ways to active a VPN tunnel. See
“Activating a VPN Tunnel” on page 7-27 for information on the other ways.
