Default Configuration and Technical Specifications
164
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
Technical Specifications
Feature General
Network Protocol and Standards Compatibility
Data and Routing Protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE or PPPoA, RFC
1483 Bridged or
Routed Ethernet, and RFC 1577 Classical IP over ATM
Power Adapter
North America 120V, 60 Hz, input
UK, Australia 240V, 50 Hz, input
Europe 230V, 50 Hz, input
All regions (output) 12V @ 1.5A output
Physical
Dimensions 8.9 in. x 6.8 in. x 1.5 in. (225.5 mm x 172 mm x 39 mm)
Weight 1.2 lbs. (0.54 kg)
Environmental
Operating temperature 0° to 40° C (32º to 104º F)
Operating humidity 10% to 90% relative humidity, noncondensing
Storage temperature –20° to 70° C (–4º to 158º F)
Regulatory Compliance
Meets requirements of FCC Part 15 Class B; VCCI Class B; EN 55 022
(CISPR 22), Class B
Interface Specifications
LAN 10BASE-T or 100BASE-Tx, RJ-45
WAN (ADSL) ITU 992.1 (G.dmt) Annex A, ITU 992.2 (G.lite), ITU 992.3 ADSL2
(G.dmt.bis), ITU 992.5 ADSL2+. Anne
x A
ADSL is supported by
DGND3300v2, Annex B ADSL is supported by DGND3300v2.
USB
File systems FAT, FAT32, and NTFS (read only)
