View connected devices
You can view a list of devices that are connected to the extender network.
To view connected devices:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 70.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Connected Devices.
The Connected Devices page displays. The devices connected to the extender
displays on the page.
User Manual25Extender Network Settings
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender
