Page #71 background image
5. Find your extender in the list and note your extender’s IP address.
Cannot Connect to the Extender
If you cannot connect to the extender, determine what prevents you from connecting:
If you cannot access www.mywifiext.net, see Cannot Access mywifiext.net on page
72 for more information.
If you forgot your user name or password, click the Username & Password Help
link. For more information, see FAQs on page 69.
If your browser displays an error page, include http:// in the address field of your
browser by typing http://www.mywifiext.net.
If you already set up the extender but can no longer connect to it over WiFi, check
to see if the Client Link LED is off.
If you cannot get a WiFi connection working, you can use an Ethernet cable to connect
your computer to the extender.
Cannot Join a WiFi Network and Receive an
Error Message
To join a WiFi network, you must know its WiFi network name (also called the SSID) so
that you can select it. If the network is secure, you must know the WiFi password (also
called the passphrase or key). If the extender does not connect to the network that you
select, the cause might be one of the following:
It is possible that you typed the WiFi network name or WiFi passowrd incorrectly.
Use Smart Setup (see Run Smart Setup Installation on page 20) to select a WiFi
network and retype the WiFi password. The WiFi password is case-sensitive. For
example, PASSWORD25 is not the same as Password25 or password25.
If the extender cannot detect your WiFi network, check to see if your WiFi network
is still working. Make sure that the WiFi router is turned on. If possible, move the
extender closer to the WiFi router.
If the extender Router Link LED is red, the WiFi connection between the WiFi router
and the extender is poor. You can establish the best connection with a clear line of
sight between the extender and the WiFi router. Make sure that no physical obstacles
exist between the extender and the WiFi router, and try to move the extender closer
to the WiFi router.
User Manual71FAQs and troubleshooting
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR EAX80 and is the answer not in the manual?

NETGEAR EAX80 Specifications

General IconGeneral
Product typeTabletop router
CertificationFCC, CE, RoHS
Product colorBlack
Indication lightYes
Power source typeDC
Package depth326 mm
Package width260 mm
Package height130 mm
Package weight1594 g
Master (outer) case width294 mm
Master (outer) case height342 mm
Master (outer) case length364 mm
Master (outer) case weight3930 g
Harmonized System (HS) code85176990
Quantity per master (outer) case2 pc(s)
DSL WAN-
WAN connection typeRJ-45
Channels quantity8 channels
WLAN data transfer rate (max)6000 Mbit/s
Modulation1024-QAM
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithms128-bit AES, AES
Ethernet LAN data rates10, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN (RJ-45) ports4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
TypeNetwork repeater
Maximum transfer distance- m
Weight and Dimensions IconWeight and Dimensions
Depth197 mm
Width106 mm
Height279 mm
Weight860 g
