NETGEAR EAX80 User Manual

Configure a router with advanced MAC
settings to work with your extender
If you enabled a WiFi MAC filter, WiFi access control, or access control list (ACL) on your
router, when a WiFi device connects through the extender to your router, the MAC
address of the WiFi device shown on the router is translated to another MAC address.
If your router’s MAC filter, WiFi access control, or ACL is enabled, the WiFi device
connects to the extender but cannot get an IP address from the extender and cannot
access the Internet.
To allow the WiFi device to receive an IP address from the extender and access the
Internet, you must provide translated MAC address to the router.
To add a translated MAC address to your router and reserve an IP address for your
extender
1.
Log in to your router and disable the MAC filter, WiFi access control, or ACL.
For more information about how to disable your router’s MAC filter, WiFi access
control, or ACL, see your router’s documentation.
2.
Power on the extender and connect all of your WiFi devices to the extender.
3. Make sure that the Router Link LED remains lit.
4. Log in to your extender:
a.
Launch a web browser from a computer or mobile device that is connected to
your extender network.
b. Log in to your extender:
•
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
A login page displays.
c. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
5. Select Settings > Connected Devices.
User Manual38Extender Network Settings
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender

NETGEAR EAX80 Specifications

General

Product type	Tabletop router
Certification	FCC, CE, RoHS
Product color	Black
Indication light	Yes
Power source type	DC
Package depth	326 mm
Package width	260 mm
Package height	130 mm
Package weight	1594 g
Master (outer) case width	294 mm
Master (outer) case height	342 mm
Master (outer) case length	364 mm
Master (outer) case weight	3930 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	2 pc(s)
DSL WAN	-
WAN connection type	RJ-45
Channels quantity	8 channels
WLAN data transfer rate (max)	6000 Mbit/s
Modulation	1024-QAM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithms	128-bit AES, AES
Ethernet LAN data rates	10, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Type	Network repeater
Maximum transfer distance	- m

Weight and Dimensions

Depth	197 mm
Width	106 mm
Height	279 mm
Weight	860 g
