NETGEAR EAX80 User Manual

LEDs
The following table describes the LEDs.
Figure 2. Front panel
Table 1. LED descriptions
DescriptionLED
•
Slow blinking white. The extender is booting, or the extender is resetting
to its factory default settings.
•
Solid white. The extender is powered on.
•
Fast blinking white. The firmware is corrupted.
•
Off. The extender is powered off.
Power LED
This LED indicates the WiFi connection between the extender and the router.
•
Solid white. Best connection.
•
Solid amber. Good connection.
•
Solid red. Poor connection.
•
Off. No connection.
Router Link LED
User Manual8Overview
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender

NETGEAR EAX80 Specifications

General

Product type	Tabletop router
Certification	FCC, CE, RoHS
Product color	Black
Indication light	Yes
Power source type	DC
Package depth	326 mm
Package width	260 mm
Package height	130 mm
Package weight	1594 g
Master (outer) case width	294 mm
Master (outer) case height	342 mm
Master (outer) case length	364 mm
Master (outer) case weight	3930 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	2 pc(s)
DSL WAN	-
WAN connection type	RJ-45
Channels quantity	8 channels
WLAN data transfer rate (max)	6000 Mbit/s
Modulation	1024-QAM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithms	128-bit AES, AES
Ethernet LAN data rates	10, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Type	Network repeater
Maximum transfer distance	- m

Weight and Dimensions

Depth	197 mm
Width	106 mm
Height	279 mm
Weight	860 g
