Back Panel
The back panel of the extender provides ports, buttons, and a DC power connector.
Figure 3. Back panel
The back panel contains the following components:
•
Reset button. Pressing this button resets the extender. If the Reset button is pressed
for at least seven seconds, the Power LED blinks amber, and the extender returns
to its factory settings.
•
Ethernet ports. Use the four Gigabit Ethernet RJ-45 LAN ports to connect the
extender to LAN devices.
•
USB 3.0 port. Use this port to connect USB storage devices to the extender.
•
DC power connector. Connect the power adapter that came in the product package
to the DC power connector.
•
Power On/Off button. Press the Power On/Off button to provide power to the
extender.
User Manual10Overview
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender
