NETGEAR EAX80 User Manual

FAQs
This section provides answers for difficulties you might experience with the extender.
The web browser setup keeps asking me for my network password (passphrase)
or security key, and I am sure that I entered the correct password. What can I do?
The extender is probably placed at the borderline of the range covered by the router
or access point. To improve your signal strength, move your extender closer to your
router and make sure that the Router Link LED lights solid white or amber.
The LED lights as follows:
•
Solid white. Best connection
•
Solid amber. Good connection
•
Solid red. Poor connection
•
Off. No connection
If you are using WEP security, make sure that you are typing the network password in
the correct field.
My router security is WEP, and I entered the wrong password or security key on
the extender. I cannot access the extender anymore. What can I do?
The extender cannot check to see if the WEP password is correct. If you entered the
wrong password, your WiFi-enabled computer or mobile device is not able to get the
IP address from the extender. You must reset the extender to its factory default settings
to get the IP address back.
Can I set up the extender in extender mode if I connect it to the router or access
point with an Ethernet cable?
No. The extender is designed to connect wirelessly to the router or access point if it is
in extender mode. If the extender is in access point mode, you can connect it to the
router or access point with an Ethernet connection. For more information about access
point mode, see Use the Extender in Access Point Mode on page 17.
I am connected to NETGEAR_EXT and launched a browser and I can’t I see the web
browser setup guide. What can I do?
Try these troubleshooting steps:
•
Make sure that the Client Link LED is white and that you are using a valid IP address.
•
Relaunch the web browser and enter www.mywifiext.net in the address field. Enter
your admin user name and password and click the LOG IN button.
User Manual69FAQs and troubleshooting
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender

NETGEAR EAX80 Specifications

General

Product type	Tabletop router
Certification	FCC, CE, RoHS
Product color	Black
Indication light	Yes
Power source type	DC
Package depth	326 mm
Package width	260 mm
Package height	130 mm
Package weight	1594 g
Master (outer) case width	294 mm
Master (outer) case height	342 mm
Master (outer) case length	364 mm
Master (outer) case weight	3930 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	2 pc(s)
DSL WAN	-
WAN connection type	RJ-45
Channels quantity	8 channels
WLAN data transfer rate (max)	6000 Mbit/s
Modulation	1024-QAM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithms	128-bit AES, AES
Ethernet LAN data rates	10, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Type	Network repeater
Maximum transfer distance	- m

Weight and Dimensions

Depth	197 mm
Width	106 mm
Height	279 mm
Weight	860 g
