NETGEAR EAX80 User Manual

•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 70.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
6. Select or clear the Enable 2.4 GHz WiFi check box.
7. Select or clear the Enable 5 GHz WiFi check box.
8. Click the SAVE button.
Your settings are saved.
Change the WiFi speed
When the extender's 2.4 GHz WiFi backhaul is connected to the root access point (root
AP), the extender's 2.4 GHz fronthaul WiFi speed is the same as the root AP's 2.4 GHz
WiFi speed. The extender cannot change its 2.4 GHz WiFi speed.
This also applies to the extender's 5 GHz WiFi speed. When the extender's 5 GHz WiFi
backhaul is connected to the root AP, the extender's 5 GHz fronthaul WiFi speed is the
same as the root AP's 5 GHz WiFi speed. The extender cannot change its 5 GHz WiFi
speed.
The following table further explains whether if the extender's 2.4 GHz or 5 GHz WiFi
speed is changeable based on which extender backhaul connection is used to connect
to the root AP.
User Manual29Extender Network Settings
Nighthawk AX8 8-Stream WiFi 6 Mesh Extender

NETGEAR EAX80 Specifications

General

Product type	Tabletop router
Certification	FCC, CE, RoHS
Product color	Black
Indication light	Yes
Power source type	DC
Package depth	326 mm
Package width	260 mm
Package height	130 mm
Package weight	1594 g
Master (outer) case width	294 mm
Master (outer) case height	342 mm
Master (outer) case length	364 mm
Master (outer) case weight	3930 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	2 pc(s)
DSL WAN	-
WAN connection type	RJ-45
Channels quantity	8 channels
WLAN data transfer rate (max)	6000 Mbit/s
Modulation	1024-QAM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithms	128-bit AES, AES
Ethernet LAN data rates	10, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Type	Network repeater
Maximum transfer distance	- m

Weight and Dimensions

Depth	197 mm
Width	106 mm
Height	279 mm
Weight	860 g
