NETGEAR EX7000 User Manual

Extender Network Settings
35
AC1900 Nighthawk WiF Mesh Extender
A login page displays.
3. Enter your admin email address and password and click the LOG IN button.
The Status page displays.
4. Click the Menu icon
.
The extender menu displays.
5. Select Settings > W
iFi Settings.
The WiFi Settings screen displays.
6. Scroll down and click the IP Address heading to expand the IP address settings.
By default, the Dynamically get IP
Address from Router radio button is selected.
7. Select the Use Static IP
Address radio button.
8. Complete the fields to specify the IP network IP addresses.
9. Click the SA
VE button.
Your settings are saved.

NETGEAR EX7000 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC1900
Number of Ethernet Ports	5
Ethernet Port Type	Gigabit
USB Ports	1 x USB 3.0
Antennas	3 external antennas
WiFi Band	Dual Band 2.4GHz and 5GHz
Processor	800MHz dual core
Security	WPA/WPA2
