Overview
7
AC1900 Nighthawk WiF Mesh Extender
Unpack Your Extender
Your box contains the following items:
Extender
Stand
Antennas (3)
Power adapter
Rubber feet (4)
Top Panel LEDs and Front Panel USB Port
Use the LEDs during installation to find the best location for the extender or to monitor the
extender performance. The following figure shows the extender in an upright position, with
the stand attached. (For information about attaching the stand, see Attach the Stand on
page 9.)
2.4 GHz Link Rate LED
5 GHz Link Rate LED
Device to Extender LED
LAN LEDs (1 through 5)
USB LED
USB 3.0 port
NETGEAR Logo LED
Figure 1. LEDs and USB port
