The following table describes the nonconfigurable information displayed on the page.
Table 26. VLAN status
Field Definition
VLAN ID The VLAN identifier (VID) of the VLAN. The range of the VLAN ID is 1
to 4093.
VLAN Name The name of the VLAN. VLAN ID 1 is always named Default.
VLAN 4089 is always named Auto-Video.
VLAN Type The VLAN type:
• Default (VLAN ID = 1).
Always present.
• Static. A
VLAN that you added.
• Auto-V
ideo. (VLAN ID = 4089). Always present.
Member Ports The ports that are included in the VLAN.
Configure Port PVID Settings
You can assign a port VLAN ID (PVID) to an interface. The following requirements apply to a
PVID:
• You must define a PVID for all ports.
• If no other value is specified, the default VLAN PVID is used.
• T
o change the port’s default PVID, you must first create a VLAN that includes the port as
a member (see Configure VLAN Membership on page 103).
 To configure PVID settings:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’
s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select Switchingï€ > VLAN >
Advanced > Port PVID Configuration.
The PVID Configuration page displays.
To Next Page
