Monitor the System
344
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
View or Clear the Event Log
You can display the event log, which is used to hold error messages for catastrophic events.
After the event is logged and the updated log is saved in flash memory, the switch is reset.
The log can hold at least 2,000 entries and is erased when an attempt is made to add an
entry after it is full. The event log is preserved across system resets.
 To view the event log or clear the log:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that is
off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select Monitoring > Logs > Event Logs.
The Event Logs page displays.
6. To refresh the page with the latest information about the switch, click the Refresh button.
7. To clear the messages from the event log, click the Clear button.
Number of Traps since log
last viewed
The number of traps that occurred since the traps were last displayed.
Displaying the traps by any method (terminal interface display, web display,
upload file from switch, and so on) causes this counter to be cleared to 0.
Log The sequence number of the trap.
System Up Time The time when the trap occurred, expressed in days, hours, minutes, and
seconds, since the last reboot of the switch.
Trap Information identifying the trap.
Table 77. Trap Logs information (continued)
Field Description
