NETGEAR GC110 User Manual

Configure Quality of Service
183
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
Packets that match an IPv6 classifier are allowed to be marked using only the 802.1p (CoS)
field or the IP DSCP field in the traffic Class octet. IP precedence is not defined for IPv6. This
is not an appropriate type of packet marking.
IPv6 ACL/DiffServ assignment is appropriate for LAG interfaces. The procedures described
by an
ACL or DiffServ policy are equally applicable on a LAG interface.
Create and Configure an IPv6 DiffServ Class
 To create and configure an IPv6 DiffServ class:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’
s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select QoS > DiffServ >
Advanced > IPv6 Class Configuration.
6. Enter a class name in the Class Name field.
The Class Name field also lists all the existing IPv6 class names, from which one can be
selected for modification or deletion.
7. From the Class T
ype menu, select the class type.
The switch supports only the class type value All, which means that all the various match
criteria defined for the class are satisfied for a packet match. All signifies the logical
AND
statement of all the match criteria. You can select the class type only when you are
creating a new class. After the class is created, the Class Type field becomes
nonconfigurable.
8. Click the Add button.
The new class is added.
