Configure Switching
95
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
• 2 Dest MAC, VLAN, EType, incoming port. This mode uses the destination MAC
address, VLAN, EtherType, and incoming port that are associated with the packet.
• 3 Src/Dest MAC, VLAN, ET
ype, incoming port. This mode uses the source and
destination MAC addresses, VLAN, EtherType, and incoming port that are associated
with the packet. This is the default mode.
• 4 Src IP and Src TCP/UDP Port fields.
This mode uses the source IP address and
source TCP or UDP port value that are associated with the packet.
• 5 Dest IP and Dest TCP/UDP Port fields.
This mode uses the destination IP address
and destination TCP or UDP port value that are associated with the packet.
• 6 Src/Dest IP and TCP/UDP Port fields.
This mode uses the source and destination
IP addresses and source and destination TCP or UDP port values that are associated
with the packet.
Note: The switch balances traffic on a port channel (LAG) by selecting one
of the links in the channel over which packets must be transmitted. The
switch selects the link by creating a binary pattern from selected fields
in a packet and associating that pattern with a particular link.
10. From the STP Mode menu, select the Spanning
Tree Protocol (STP) administrative mode
associated with the LAG. The possible values are as follows:
• Disable. Spanning tree is disabled for this LAG.
• Enable. Spanning tree is enabled for this LAG. Enable is the default.
11. From the Link T
rap menu, select Enable or Disable to specify whether to send a trap when
the link status changes.
The default is Enable, which causes the trap to be sent.
12. From the LAG T
ype menu, select Static or LACP:
• Static. Disables Link
Aggregation Control Protocol (LACP) on the selected LAG. The
LAG is configured manually. The default is Static.
• LACP. Disables LACP on the selected LA.
The LAG is configured automatically.
13. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Table 23. LAG Configuration information
Field Description
LAG ID Identifier of the LAG.
Active Ports The ports that are actively participating in the LAG.
LAG State Indicates whether the link is up or down.
