NETGEAR GS110TUP - Page 26

1
2
3
4
4
Figure 7. Sample PoE++ lighting configuration
PoE++ Non-PoE
DeviceNumberDeviceNumber
Internet3Switch model GS710TUP1
LED lighting in an office room4Router2
Hardware Installation Guide26Applications
10-Port Gigabit Ethernet Ultra60 PoE++ Smart Managed Pro Desktop and Rackmount Switches
