DeviceNumberDeviceNumber
PoE++ PTZ camera4Switch model GS710TUP1
ReadyNAS storage system5Router2
Internet3
Ultra60 PoE++ for PoE lighting in smart
buildings
The switch supports Ultra60 PoE++ with a very high PoE budget of 480W so that it can
provide low-voltage power for PoE lighting in smart buildings. The following figure
shows a PoE lighting sample configuration in which eight office rooms are illuminated
through PoE LED lights that are powered through the PoE++ ports (1–8) on the switch.
In this sample configuration, connect the Ethernet uplink port (port 9 in the following
figure) on the switch to a LAN port on a router (see 2) that is connected to the Internet
(see 3). You can also make a 1 Gbps fiber connection from port 10 on the switch to a
router that supports fiber, and which is connected to the Internet or to another device
that supports fiber.
The following figure shows model GS710TUP. A similar sample configuration could
apply to model GS110TUP if you attach LED lighting to ports 1–4 only. (On model
GS110TUP, ports 5–8 support PoE+, not PoE++.)
Hardware Installation Guide25Applications
10-Port Gigabit Ethernet Ultra60 PoE++ Smart Managed Pro Desktop and Rackmount Switches
