GS700TS Smart Switch Software Administration Manual
4-7 Configuring Switching Settings
v1.0, June 2009
LAG Membership
The Basic LAG Membership screen allows network managers to assign ports to LAGs.
To assign ports to LAGs:
1. Click Switching > LAG > Basic > LAG Membership. The Basic LAG Membership screen
displays:
The Basic LAG Membership screen contains the following fields:
• LAG ID – Select the LAG ID.
• LAG Name – Displays the user-defined LAG name.
• LAG Type – Select the LAG type. The possible field values are:
– Static – Indicates the LAG is configured manually.
– LACP – Indicates the LAG is configured dynamically.
2. Select the LAG ID and LAG Type.
3. Click on the unit’s gold button. The unit’s port panel displays.
4. Select the ports to be members of the LAG.
5. Click APPLY to update the device.
6. Click CURRENT MEMBERS. The Current Members window opens and displays the
member ports included in the LAG:
Figure 4-3
