GS700TS Smart Switch Software Administration Manual
Configuring Switching Settings 4-48
v1.0, June 2009
• VLAN Name – Displays the user-defined VLAN name.
• Multicast Address – Enter the Multicast group MAC Address associated with the VLAN.
• Type – Indicates the VLAN ID status in relation to the Multicast group.
– Static – Attaches the VLAN ID to the Multicast group as static member.
– Dynamic – Dynamically joins the VLAN ID to the Multicast group.
2. Select the group entry.
3. Enter the Multicast Address in the provided field in the first row.
4. Click APPLY to update the device.
Multicast Group Membership
The Multicast Group Membership screen displays the ports and LAGs attached to the selected
VLAN and the Multicast service group. The Port and LAG tables also reflect the manner in which
the port or LAGs joined the Multicast group.
To configure Multicast group membership:
1. Click Switching > Multicast > Advanced > Multicast Group Membership.
The Multicast
Group Membership screen displays:
Figure 4-30
