GS700TS Smart Switch Software Administration Manual
7-19 Monitoring the Switch
v1.0, June 2009
4. Select the event Type from the list in the provided field in the first row.
5. Click APPLY to update the device.
To add an events control entry:
1. Click Monitoring > RMON > Advanced > Events Control. The RMON Events Control
screen displays.
2. Enter the Community, Description and Owner in the provided field in the first row.
3. Select the event Type from the list in the provided field in the first row.
4. Click ADD to update the device.
To remove an events control entry:
1. Click Monitoring > RMON > Advanced > Events Control. The RMON Events Control
screen displays.
2. Select the events control entry.
3. Click DELETE to remove the events control entry.
Events Log
The RMON Events Log screen contains a list of RMON events.
To view RMON events logs:
1. Click Monitoring > RMON > Advanced > Events Log. The RMON Events Log screen
displays:
Figure 7-11
