GS700TS Smart Switch Software Administration Manual
3-47 Managing System Settings
v1.0, June 2009
To remove a network policy entry:
1. Click System > LLDP > Advanced > LLDP-MED Network Policy. The LLDP-MED
Network Policy screen displays.
2. Select the Network Policy entry.
3. Click DELETE to remove the entry.
LLDP-MED Port Settings
The LLDP-MED Port Settings screen contains parameters for assigning LLDP-MED network
policies to specific ports.
To configure LLDP-MED port settings:
1. Click System > LLDP > Advanced > LLDP-MED Port Settings. The LLDP-MED Port
Settings screen displays:
The LLDP-MED Port Settings screen contains the following fields:
• Port – Select the port to configure.
• LLDP-MED status – Select the LLDP-MED status for the selected port. The possible
field values are:
– Enable – Enables LLDP-MED on the selected port.
– Disable – Disables LLDP-MED on the selected port.
• Notification – Select the notification status for the selected port. The possible field values
are:
– Enable – Enables notification on the selected port.
Figure 3-25
