1
Introduction and Hardware Overview
This manual is for the following NETGEAR
®
LTE Modem LB2120 models:
LB2120-100AUS. Data model with one LAN and one WAN Gigabit Ethernet port and with band support for
the Australia, New Zealand, and Oceania region.
LB2120-100EUS. Data model with one LAN and one WAN Gigabit Ethernet port and with band support for
the Europe, South Africa, and Middle East region.
LB2120-100NAS. Data model with one LAN and one WAN Gigabit Ethernet port and with band support for
the North America region.
The LTE Modem LB2120 provides two Gigabit Ethernet ports: one LAN port for connection to a router, switch,
hub, or computer and one WAN port for connection to a wireline broadband modem in support of automatic
failover to mobile broadband if the wireline broadband modem goes down.
This chapter provides an introduction and hardware overview of the LTE Modem LB2120 and contains the
following sections:
Introduction on page 7
Supported Mobile Broadband Bands on page 7
Package Contents on page 8
Install the Micro SIM Card on page 8
Top Panel With Status LEDs on page 11
Back Panel With Ports, Connectors, and Button on page 12
Modem Label on page 12
Position the Modem on page 13
Optional External Antenna on page 14
For more information about the topics that are covered in this manual, visit the support website
at netgear.com/support.
Note
Firmware updates with new features and bug fixes are made available from time to time at
downloadcenter.netgear.com.You can check for and download new firmware manually. If
the features or behavior of your product does not match what is described in this guide, you
might need to update your firmware.
Note
6
