To detach two connected half-width switches:
1.
Place the connected switches upside down on a flat surface.
2.
At the bottom of one of the switches, locate the small rectangular hole that is closest
to the other switch.
The hole provides a small metal blade that is pressed against one side of the hole.
3.
Insert the tip of a slotted screwdriver between the metal blade and the side of the
hole.
4.
Force the metal blade away from the side, unlocking the two switches.
5.
With the switches unlocked, push them apart until the screws at the side of one
switch are aligned with the holes on the side of the other switch.
6.
Pull the screws from the holes, thereby detaching the switches.
CAUTION: After unlocking the switches, be careful with the metal hooks that extend
from the side of one of the switches. Although the hooks are not sharp, they stand
out from the side.
Hardware Installation Guide61Installation
Fully Managed Switches M4350 Series
