NETGEAR MS108EUP Hardware Installation Guide

LEDs
This section describes the LED designations.
Table 1. LEDs on the front panel
DescriptionLED
Solid green. The switch is powered on and operating normally.
Blinking green. The switch is booting.
Off. Power is not supplied to the switch.
Power LED
Off. Sufficient (more than 7W of) PoE power is available.
Solid yellow. Less than 7W of PoE power is available.
Blinking yellow. At least once during the previous two minutes, less than 7W of PoE
power was available.
PoE Max LED
(The status of the switch’s
PoE budget.)
Solid green. A valid 2.5 Gbps link is established.
Blinking green. The port is transmitting or receiving packets at 2.5 Gbps.
Solid yellow. A valid 1000 Mbps or 100 Mbps link is established.
Blinking yellow. The port is transmitting or receiving packets at 1000 Mbps or
100 Mbps.
Off. No port link is established.
Ports 1–8 left LED
Link, speed, and activity for
Ethernet ports 1 to 8
Off. The port is not delivering PoE power.
Solid green. The port is delivering PoE power.
Solid yellow. A PoE fault occurred.
Ports 1–8 right LED
PoE status for Ethernet ports
1 to 8.
Hardware Installation Guide13Hardware Overview
8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Plus Switch MS108EUP

NETGEAR MS108EUP Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Port-based VLAN, Tagged VLAN
Copper ethernet cabling technology	100BASE-T, 1000BASE-T
Jumbo frames	12000
MAC address table	16000 entries
Packet buffer memory	1.5 MB
DHCP features	DHCP client
Queue scheduling algorithms	Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Number of multicast groups filtered	128
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Total Power over Ethernet (PoE) budget	230 W
Power source	PoE
Mean time between failures (MTBF)	373644 h
Certification	CE FCC 15 B CE/EN55032/24 CSA VCCI ACMA KC CCC BSMI
Product color	Gray
Housing material	Metal

Weight and Dimensions

Depth	140 mm
Width	210 mm
Height	40 mm
Weight	900 g
