NETGEAR MS108EUP Hardware Installation Guide

Step 5: Connect devices to the switch
This switch is designed for indoor use only. If you want to connect to a device located
outdoors, the outdoor device must be properly grounded and surge protected, and
you must install an Ethernet surge protector inline between the switch and the outdoor
device. Failure to do so can damage the switch.
WARNING: Before connecting this switch to outdoor cables or devices, see
https://kb.netgear.com/000057103 for safety and warranty information.
The following procedure describes how to connect devices to the switch’s RJ-45 ports.
The switch supports Auto Uplink technology, which allows you to attach devices using
either straight-through or crossover cables. Use a Category 5e (Cat 5e) or Cat 6 cable
that is terminated with an RJ-45 connector.
To connect devices to the switch’s RJ-45 ports:
1. Connect a PoE or non-PoE device to an RJ-45 network port on the switch.
Ethernet specifications limit the cable length between the switch and the attached
device to 328 feet (100 meters).
2.
Verify that all cables are installed correctly.
Step 6: Check the installation
Before you apply power to the switch, perform the following steps.
To check the installation:
1. Inspect the equipment thoroughly.
2.
Verify that all cables are installed correctly.
3.
Check cable routing to make sure that cables are not damaged or creating a safety
hazard.
4. Make sure that all equipment is mounted properly and securely.
Hardware Installation Guide25Installation
8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Plus Switch MS108EUP

NETGEAR MS108EUP Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Port-based VLAN, Tagged VLAN
Copper ethernet cabling technology	100BASE-T, 1000BASE-T
Jumbo frames	12000
MAC address table	16000 entries
Packet buffer memory	1.5 MB
DHCP features	DHCP client
Queue scheduling algorithms	Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Number of multicast groups filtered	128
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Total Power over Ethernet (PoE) budget	230 W
Power source	PoE
Mean time between failures (MTBF)	373644 h
Certification	CE FCC 15 B CE/EN55032/24 CSA VCCI ACMA KC CCC BSMI
Product color	Gray
Housing material	Metal

Weight and Dimensions

Depth	140 mm
Width	210 mm
Height	40 mm
Weight	900 g
