NETGEAR MS108EUP Hardware Installation Guide

1
Introduction
This hardware installation guide complements the installation guide that came with your
switch and applies to the NETGEAR 8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet
Plus Switch Model MS108EUP.
The switch provides eight Multi-Gigabit Ethernet copper ports that each can support
2.5 Gbps, 1 Gbps, and 100 Mbps speed. Ports 1–4 support Ultra60 PoE++ (802.3bt) so
that each port can deliver power of up to 60W PoE++ to devices such as WiFi 6 access
points, security cameras, PoE speakers, and LED lighting. Ports 5–8 each can deliver
power of up to 30W PoE+ (802.3at) to devices that do not require high power. The
maximum PoE power budget of the switch across all active PoE+ and PoE++ ports is
230W.
This chapter serves as an introduction to the switch and includes the following sections:
• Overview
• Features
• Safety instructions and warnings
Note: For more information about the topics that are covered in this manual, visit the
support website at netgear.com/support.
Note: For technical specifications, see the data sheet at
https://www.netgear.com/business/wired/switches/plus. For switch documentation,
including the installation guide and user manual, visit netgear.com/support/download.
5

NETGEAR MS108EUP Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Port-based VLAN, Tagged VLAN
Copper ethernet cabling technology	100BASE-T, 1000BASE-T
Jumbo frames	12000
MAC address table	16000 entries
Packet buffer memory	1.5 MB
DHCP features	DHCP client
Queue scheduling algorithms	Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Number of multicast groups filtered	128
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Total Power over Ethernet (PoE) budget	230 W
Power source	PoE
Mean time between failures (MTBF)	373644 h
Certification	CE FCC 15 B CE/EN55032/24 CSA VCCI ACMA KC CCC BSMI
Product color	Gray
Housing material	Metal

Weight and Dimensions

Depth	140 mm
Width	210 mm
Height	40 mm
Weight	900 g
