Operate the product only from the type of external power source indicated on the
electrical ratings label. If you are not sure of the type of power source required,
consult your service provider or local power company.
To avoid damaging your system, if your product uses a power supply with a voltage
selector, be sure that the selector is set to match the power at your location:
-
115V, 60 Hz in most of North and South America and some Far Eastern countries
such as South Korea and Taiwan
- 100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan
-
230V, 50 Hz in most of Europe, the Middle East, and the Far East
Be sure that attached devices are electrically rated to operate with the power available
in your location.
Depending on your product, use only a supplied power adapter or approved power
cable:
If your product uses a power adapter:
-
If you were not provided with a power adapter, contact your local NETGEAR
reseller.
-
The power adapter must be rated for the product and for the voltage and current
marked on the product electrical ratings label.
If your product uses a power cable:
-
If you were not provided with a power cable for your system or for any
AC-powered option intended for your system, purchase a power cable approved
for your country.
-
The power cable must be rated for the product and for the voltage and current
marked on the product electrical ratings label. The voltage and current rating of
the cable must be greater than the ratings marked on the product.
To help prevent electric shock, plug the system and peripheral power cables into
properly grounded power outlets.
If applicable to your product, the peripheral power cables are equipped with
three-prong plugs to help ensure proper grounding. Do not use adapter plugs or
remove the grounding prong from a cable. If you must use an extension cable, use
a three-wire cable with properly grounded plugs.
Observe extension cable and power strip ratings. Make sure that the total ampere
rating of all products plugged into the extension cable or power strip does not
exceed 80 percent of the ampere ratings limit for the extension cable or power strip.
Hardware Installation Guide9Introduction
8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Plus Switch MS108EUP

Other manuals for NETGEAR MS108EUP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR MS108EUP and is the answer not in the manual?

NETGEAR MS108EUP Specifications

General IconGeneral
Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes
Installed SFP modules quantity-
Basic switching RJ-45 Ethernet ports type2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Number of VLANs64
Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Virtual LAN featuresPort-based VLAN, Tagged VLAN
Copper ethernet cabling technology100BASE-T, 1000BASE-T
Jumbo frames12000
MAC address table16000 entries
Packet buffer memory1.5 MB
DHCP featuresDHCP client
Queue scheduling algorithmsStrict Priority Queue (SPQ), Weighted Round Robin (WRR)
Number of multicast groups filtered128
Operating altitude0 - 3000 m
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)0 - 90 %
Total Power over Ethernet (PoE) budget230 W
Power sourcePoE
Mean time between failures (MTBF)373644 h
CertificationCE FCC 15 B CE/EN55032/24 CSA VCCI ACMA KC CCC BSMI
Product colorGray
Housing materialMetal
Weight and Dimensions IconWeight and Dimensions
Depth140 mm
Width210 mm
Height40 mm
Weight900 g
