NETGEAR Nighthawk M1 User Manual

Recharge the Battery From a Wall Socket
To recharge the battery from a wall socket:
1. Attach one end of the micro USB cable to the connector on the right on the mobile router and attach
the other end to the wall charger (included).
2. Plug the wall charger into a wall socket.
The Battery bar on the LCD indicates that the battery is charging.
The battery continues to charge when the mobile router is powered off.Note
If your battery does not charge, check the following:
• Is the mobile router hot? If you are in a low-coverage area, are transferring a lot of data, or left the
mobile router in a hot location, the internal temperature of the mobile router can rise above 45°C.
In these conditions, the battery cannot be charged due to safety limits with lithium-ion battery
technology.
• Make sure that the USB cable and the AC wall charger are connected securely and are working
correctly.
• If the wall socket is controlled by a switch, make sure that the switch is in the power-on position.
Manage Battery Usage and Charging
22
Nighthawk LTE Mobile Hotspot Router Model MR1100

NETGEAR Nighthawk M1 Specifications

General

Model	MR1100
WiFi Technology	802.11ac
WiFi Speed	Up to 1 Gbps
Battery	5040 mAh
Dimensions	105.5 x 105.5 x 20.35 mm
Weight	240 g
LTE Category	LTE CAT 16
Max Theoretical Downlink Speed	1 Gbps
Max Theoretical Uplink Speed	150 Mbps
Wi-Fi Bands	2.4 GHz, 5 GHz
Wi-Fi Max Theoretical Speed	1 Gbps
SIM Type	Nano SIM
Ethernet Ports	1 x Gigabit Ethernet
USB Ports	1 x USB 3.0
SIM Card Slot	Yes (Nano)
External Antenna Ports	2 TS-9 connectors
