NETGEAR Nighthawk M1 User Manual

Recharge the Battery From a Computer USB Port
To recharge the battery from the USB port on your computer:
Attach one end of the micro USB cable to the mobile router and plug the other end into the USB port
on your computer.
The Battery bar on the LCD indicates that the battery is charging.
The LCD goes into sleep mode after a set time to extend battery life.To wake up the
LCD, press and quickly release the Power button.
Note
Use the USB Type C Cable to Charge Only
You can log in to the mobile router and specify a setting so that the USB type C cable is used only for
charging and not to access the mobile router using a web browser.You might want to do this if you are
using the Ethernet port and a wall socket is not available to charge the mobile router.
To specify a USB type C cable charge-only setting:
1. From a computer that is connected to your network, launch a web browser.
2. Enter http://192.168.1.1.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The user name and password are case-sensitive.
The mobile router dashboard displays.
4. Select Setup > Router Setup.
Manage Battery Usage and Charging
23
Nighthawk LTE Mobile Hotspot Router Model MR1100

NETGEAR Nighthawk M1 Specifications

General

Model	MR1100
WiFi Technology	802.11ac
WiFi Speed	Up to 1 Gbps
Battery	5040 mAh
Dimensions	105.5 x 105.5 x 20.35 mm
Weight	240 g
LTE Category	LTE CAT 16
Max Theoretical Downlink Speed	1 Gbps
Max Theoretical Uplink Speed	150 Mbps
Wi-Fi Bands	2.4 GHz, 5 GHz
Wi-Fi Max Theoretical Speed	1 Gbps
SIM Type	Nano SIM
Ethernet Ports	1 x Gigabit Ethernet
USB Ports	1 x USB 3.0
SIM Card Slot	Yes (Nano)
External Antenna Ports	2 TS-9 connectors
