NETGEAR R9000 User Manual

Table 1. LED descriptions (Continued)
DescriptionLED
• Solid white.The 2.4 GHz WiFi radio is operating.
• Blinking.The router is sending or receiving WiFi traffic.
• Off.The 2.4 GHz WiFi radio is off.
2.4 GHz WiFi
• Solid white.The 5 GHz WiFi radio is operating.
• Blinking.The router is sending or receiving WiFi traffic.
• Off.The 5 GHz WiFi radio is off.
5 GHz WiFi
• Solid white.The 60 GHz WiFi radio is operating.
• Blinking.The router is sending or receiving WiFi traffic.
• Off.The 60 GHz WiFi radio is off.
60 GHz WiFi
• Solid white.The 2.4 GHz guest WiFi radio or the 5 guest GHz WiFi radio is operating.
• Off.The guest WiFi radio is off.
Guest WiFi
• Solid white. A USB device is connected and is ready.
• Blinking. A USB device is plugged in and is trying to connect.
• Off. No USB device is connected, or someone clicked the Safely Remove Hardware button
and it is now safe to remove the attached USB device.
USB 3.0 port 1 and USB 2.0
port 2
• Solid white. A powered-on device is connected to the 10G LAN SFP+ port.
• Blinking.The port is sending or receiving traffic.
• Off. No device is connected to the 10G LAN SFP+ port.
10G
The LED color indicates the speed: white for Gigabit Ethernet connections and amber for 100
Mbps or 10 Mbps Ethernet connections.
• Solid. A powered-on device is connected to the Ethernet port.
• Blinking.The port is sending or receiving traffic.
• Off. No device is connected to this Ethernet port.
Ethernet ports 1–4
Hardware Setup
11
Nighthawk X10 AD7200 Smart WiFi Router

NETGEAR R9000 Specifications

General

Processor	1.7GHz Quad-Core Processor
RAM	1GB
Flash Memory	512MB
WiFi Technology	802.11ac
WiFi Band	2.4GHz, 5GHz
Ethernet Ports	6 x 10/100/1000Mbps Gigabit Ethernet ports
USB Ports	Two USB 3.0 ports
Antenna	4 external antennas
Security	WPA/WPA2-PSK
