Front View
The status LEDs are located on the top of the router.The USB ports are located on the side of the router.
The four active antennas include LEDs. If the LEDs on the active antennas are lit, the WiFi radios are
operating.
Figure 2. Front view
Table 1. LED descriptions
DescriptionLED
Solid white.The router is ready.
Blinking white.The router is not ready, firmware is upgrading, or the Reset button was
pressed.
Off. Power is not supplied to the router.
Power
Solid white. An Ethernet connection is established.
Blinking white.The port is sending or receiving traffic.
Off. No Ethernet cable is connected between the router and the modem.
Internet
Hardware Setup
10
Nighthawk X10 AD7200 Smart WiFi Router

Table of Contents

Other manuals for NETGEAR R9000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R9000 and is the answer not in the manual?

NETGEAR R9000 Specifications

General IconGeneral
Processor1.7GHz Quad-Core Processor
RAM1GB
Flash Memory512MB
WiFi Technology802.11ac
WiFi Band2.4GHz, 5GHz
Ethernet Ports6 x 10/100/1000Mbps Gigabit Ethernet ports
USB PortsTwo USB 3.0 ports
Antenna4 external antennas
SecurityWPA/WPA2-PSK
