The service is now in the Portmap Table.You must enable port triggering before the router uses port
triggering. See Enable Port Triggering on page 144.
Enable Port Triggering
To enable port triggering:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > Port Forwarding/Port Triggering.
The Port Forwarding/Port Triggering page displays.
5. Select the Port Triggering radio button.
6. Clear the Disable Port Triggering check box.
If this check box is selected, the router does not use port triggering even if you specified port triggering
settings.
7. In the Port Triggering Timeout field, enter a value up to 9999 minutes.
This value controls how long the inbound ports stay open when the router detects no activity.This value
is required because the router cannot detect when the application terminates.
8. Click the Apply button.
Your settings are saved.
Application Example: Port Triggering for Internet Relay Chat
Some application servers, such as FTP and IRC servers, send replies to multiple port numbers. Using port
triggering, you can tell the router to open more incoming ports when a particular outgoing port starts a
session.
An example is Internet Relay Chat (IRC).Your computer connects to an IRC server at destination port 6667.
The IRC server not only responds to your originating source port but also sends an “identify” message to
your computer on port 113. Using port triggering, you can tell the router, “When you initiate a session with
destination port 6667, you must also allow incoming traffic on port 113 to reach the originating computer.”
The following sequence shows the effects of this port triggering rule:
1. You open an IRC client program to start a chat session on your computer.
2. Your IRC client composes a request message to an IRC server using a destination port number of 6667,
the standard port number for an IRC server process.Your computer then sends this request message
to your router.
Customize Internet Traffic Rules for Ports
144
Nighthawk X10 AD7200 Smart WiFi Router
