Reference Manual for the NETGEAR ProSafe Wireless Access Point 802.11g WG302
Advanced Configuration 5-11
July 2005 v3.0
• All WG302 Access Points use the same SSID, Channel, authentication mode, if any, and
encryption in use.
• All Point-to-Point APs must have AP2’s MAC address in its Remote AP MAC address
field.
3. Verify connectivity across the LANs.
• A computer on any LAN segment should be able to connect to the Internet or share files
and printers with any other PCs or servers connected to any of the three LAN segments.
• Wireless stations will not be able to connect to the WG302 Access Points in the
illustration above. If you require wireless stations to access any lan segment, you can
additional WG302 Access Points configured in Wireless Access Point mode to any LAN
segment.
Note: You can extend this multi-point bridging by adding additional WG302s configured in
Point-to-Point mode for each additional LAN segment. Furthermore, you can extend the range of
the wireless network with NETGEAR wireless antenna accessories.
How to Configure Wireless Repeating
Figure 5-9: Multi-Point bridging
1.
Configure the Operating Mode of the WG302 Access Points.
– WG302 (AP1) on LAN Segment 1 in Repeater mode with the Remote MAC Address of
AP2.
– Configure WG302 (AP2) in Repeater mode with MAC addresses of AP1 and AP3.
AP in Repeater Mode
with client associations
LAN
Segment 1
192.168.0.1
Router
AP in Repeater Mode
with client associations
AP in Repeater Mode
with client associations
AP1
ETHERNET
RESET
5-12V DC
AP3
ETHERNET
RESET
5-12V DC
AP2
ETHERNET
RESET
5-12V DC
Wireless PC
Associated with AP3
Wireless PC
Associated with AP2
Wireless PC
Associated with AP1
