Reference Manual for Cable/DSL Wireless Router WGR614
Connecting the Router to the Internet 2-5
Note: Place the WGR614 router in a location which conforms to the “Observe
Performance, Placement, and Range Guidelines” on page 3-1. The stand provided with the
WGR614 provides a convenient, space-saving way of installing the router. Avoid stacking
it on other electronic equipment.
Figure 2-2: Connect the cable or DSL Modem to the router
d. Connect the Ethernet cable which came with the router from a Local port on the router (B)
to your computer.
Figure 2-3: Connect the computers on your network to the router
Note: The WGR614 router incorporates Auto Uplink
TM
technology. Each LOCAL
Ethernet port will automatically sense if the cable should have a normal connection or an
uplink connection. This feature eliminates the need to worry about crossover cables
because Auto Uplink will make the right connection either type of cable.
Cable
or DSL modem
A
Cable or
DSL modem
B

NETGEAR WGR614 Specifications

Power

power adapter voltage	12 VDC

Interface and Networking

internet WAN	10/100 Mbps (auto-sensing) Ethernet, RJ-45
LAN ports	4 ports 10/100 Mbps (auto-sensing) Ethernet, RJ-45
wireless network speeds	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, & 54 Mbps (auto-rate capable)

Wireless Specifications

modulation type	OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK
frequency range US	2.412 ~ 2.462 GHz
frequency range Japan	2.412 ~ 2.484 GHz
frequency range Europe ETSI	2.412 ~ 2.472 GHz
frequency range Spain	2.457 ~ 2.462 GHz
frequency range France	2.457 ~ 2.472 GHz

Security

encryption	40-bit (also called 64-bit), 128-bit, and 152-bit (802.11g only) WEP encryption, WPA (Wi-Fi Protected Access)
firewall	Stateful Packet Inspection (SPI), DoS Attack Detection/Logging, Dropped Packet Log, Security Event Log, E-mail Log

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	0.3 kg (0.7 lb)
antenna gain	2 dBi
