NETGEAR WGR614 User Manual

Reference Manual for Cable/DSL Wireless Router WGR614
Wireless Configuration 3-7
Before You Change the SSID and WEP Settings
Before customizing your wireless settings, print this form and record the following information. If
your working with an existing wireless network, the person who set up or is responsible for the
network will be able to provide this information. Otherwise, you will choose the settings for your
wireless network. Either way, record the settings for your wireless network in the spaces below.
• Network Name (SSID): The Service Set Identification (SSID), called the wireless
network name in Windows XP, identifies the wireless network. You may use up to 32
alphanumeric characters. Record your customized SSID on the line below.
Name (SSID):______________________________
Note: The SSID in the router is the SSID you configure in the wireless adapter card. For
the access point and wireless nodes to communicate with each other, all must be
configured with the same SSID.
• Authentication. The authentication setting, “Open System” or “Shared Key,” is unrelated
to encryption of transmissions. The two bands can use different authentication settings.
Choose “Shared Key” for more security, circle one: Open System or Shared Key
Note: If you select shared key, the other devices in the network will not connect unless
they are set to Shared Key as well.
• WEP Encryption Strength. Choose the key size. Circle one: 64 or 128 bits.
• WEP Encryption Keys.
There are two methods for creating WEP encryption keys:
– Passphrase. ______________________________ Enter a word or group of printable
characters. These characters are case sensitive. When you enter the Passphrase and
click the Generate button on the WGR614, the keys will be generated.
– Manual. For 64-bit WEP, enter 10 hexadecimal digits (any combination of 0-9 or a-f).
These values are not case sensitive. For 128-bit WEP, enter 26 hexadecimal digits.
Whichever method you use, record the key values in the spaces below.
Key 1: ___________________________________
Key 2: ___________________________________
Key 3: ___________________________________
Key 4: ___________________________________
Use the procedures described in the following sections to configure the WGR614. Store this
information in a safe place.

NETGEAR WGR614 Specifications

Power

power adapter voltage	12 VDC

Interface and Networking

internet WAN	10/100 Mbps (auto-sensing) Ethernet, RJ-45
LAN ports	4 ports 10/100 Mbps (auto-sensing) Ethernet, RJ-45
wireless network speeds	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, & 54 Mbps (auto-rate capable)

Wireless Specifications

modulation type	OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK
frequency range US	2.412 ~ 2.462 GHz
frequency range Japan	2.412 ~ 2.484 GHz
frequency range Europe ETSI	2.412 ~ 2.472 GHz
frequency range Spain	2.457 ~ 2.462 GHz
frequency range France	2.457 ~ 2.472 GHz

Security

encryption	40-bit (also called 64-bit), 128-bit, and 152-bit (802.11g only) WEP encryption, WPA (Wi-Fi Protected Access)
firewall	Stateful Packet Inspection (SPI), DoS Attack Detection/Logging, Dropped Packet Log, Security Event Log, E-mail Log

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	0.3 kg (0.7 lb)
antenna gain	2 dBi
