geniumNet
AUG3201-IP Cong Guide
© Copyright Netgenium Systems 2017 Page 3
This chapter describes how to set up the AUG3201-IP for connectivity to the
LAN and congure the unit in its environment.
Initial Network Setup
Connect the AUG3201-IP to a PoE capable network switch or via a mid-span
device.
To logon for the rst time, open a web browser and type the IP address of the
gateway in the address bar. Each unit is pre-congured with a default IP
address of 10.100.1.173 when it leaves the factory.
The default username and password are as follows:
Username: netgenium
Password: netgenium
The home page provides basic information on the unit such as software
version serial number etc. Navigation around the menu structure is via the tabs
shown at the top of the home page. Each tab redirects the browser to the
master page for the conguration section selected. In each section a sub menu
is accessible via the links on the left of the page.
1
Conguration
