DRIVER’S AREA
42 Copyright © 1998 New Flyer Industries Ltd.
Figure 17: Fire Suppression Controls
1
7
4
2
6
3
5
8
9
10
11
12
op1901a.wmf
1. Nitrogen Gas Canister
2. Engine Shut Down Control Box
3. Actuator Mounting Bracket
4. Squib
5. Actuation Line (Extinguisher)
6. Actuation Line (Engine Shutdown)
7. Palm Button
8. Audible Alarm
9. Silence Engaged Ind. LED
10. Push to Silence Button
11. Fire Ind. LED (red)
12. System OK Ind. LED (green)
