Modem Reference Manual for EL470 IP Satellite Modem
Command
DmIntRate
Interface rate Interface rate
Location /Modem/Control/Demodulation
Description
Configuration of the nominal interface rate. When automatic detection
(ACM or auto-CCM) of FEC and modulation mode is enabled, the operator
can only enter a specific symbol rate while the interface rate will indicate
auto. In DVB-DSNG mode, this parameter is always manually adaptable.
RMCP
Command
RRr Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmIntRate
OID 1.3.6.1.4.1.5835.3.1.13.1.14.1.1
Values GUI Unit
Mbps
Cmd Unit Factory Default (CU)
bps 33.000000
Expert Range (CU)
1290000 ..
110000000
Command
DmSynRate
Symbol rate Symbol rate
Location /Modem/Control/Demodulation
Description
Configuration of the nominal symbol rate. The actual possible range
depends on the hardware installed and can be limited by a software
capability key.
RMCP
Command
RRs Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmSynRate
OID 1.3.6.1.4.1.5835.3.1.13.1.25.1.1
Values GUI Unit
Mbaud
Cmd Unit Factory Default (CU)
baud 27.500000
Expert Range (CU)
-1e+38 .. 1e+38
Command
DmAcqRan
Acquisition range (ptp) Acquisition range (p
Location /Modem/Control/Demodulation
Description
Configuration of the range for the carrier acquisition sweep (peak-to-peak).
A larger acquisition range will allow locking more easily on an unstable
frequency but will also increase demodulator synchronisation time.
RMCP
Command
RDr Access Normal user : no
access
Expert user : RW
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmAcqRan
OID 1.3.6.1.4.1.5835.3.1.13.1.3.1.1
Values GUI Unit
KHz
Cmd Unit Factory Default (CU)
Hz 1.000.000
Expert Range (CU)
50000 ,,,,,, 7500000
version 3.1
101
