User Manual
for the
Satellite Terminal
version 3.0

Table of Contents

Questions and Answers

  • P
    Patrick HarperAug 18, 2025
    What to do if Newtec TP210 shows 'No demodulator lock' and the RX LED is off?
    • H
      Hannah HughesAug 18, 2025
      If the Newtec Modem web interface displays 'No demodulator lock' and the modem LED is red with the RX indicator LED off, it indicates an error in handling the Rx signal, meaning the Rx demodulator cannot lock. To solve this, verify the antenna pointing, ensure the connectivity between the IPmodem and the antenna, and check the configuration of the satellite interface, including frequency, polarisation, and symbol rate.
  • S
    Stacey CummingsAug 20, 2025
    What to do if Newtec TP210 Modem shows 'Network lookup failed'?
    • T
      Tim SmithAug 20, 2025
      If the Newtec Modem web interface displays 'Network lookup failed' and the Warning LED and RX LED are on, this may be due to pointing to the wrong satellite. You should verify the satellite interface configuration and check if the antenna is pointed correctly. If needed, re-point the antenna and reset the IPmodem. If the problem persists for more than four hours, contact your ISP.
  • T
    tmorrisonAug 23, 2025
    How to fix no connectivity with Newtec TP210 Modem web interface?
    • L
      lauren76Aug 23, 2025
      To regain connectivity with the Newtec IPmodem web interface, first, check if your computer can receive an IP address via DHCP. If it can, unplug the Ethernet cable from your computer, wait for more than three minutes, and then plug it back in.
  • J
    jorge54Aug 26, 2025
    What to do if Newtec TP210 Modem shows 'Network connectivity lost'?
    • R
      Rebecca OdomAug 26, 2025
      If the Newtec Modem web interface shows 'Network connectivity lost' and the Warning LED and RX LED are on, it means the connection with the satellite network is lost. Try resetting the IPmodem. If the error continues for more than four hours, contact your ISP.
  • K
    Kelsey BrownAug 28, 2025
    What to do if Newtec Modem shows 'Synchronisation process failed'?
    • K
      Kristin LesterAug 28, 2025
      If the Newtec Modem web interface displays 'Synchronisation process failed' and the Warning LED and RX LED are on, it indicates that the time synchronisation process has failed. To resolve this, reset the IPmodem. If the error persists for more than four hours, contact your ISP, as it could indicate a general network problem.
  • E
    edwardmurilloAug 30, 2025
    What to do if Newtec TP210 Modem shows 'Synchronisation lost'?
    • K
      kimberly38Aug 30, 2025
      If the Newtec Modem web interface displays 'Synchronisation lost' and the Warning LED and RX LED are on, it means the time synchronisation is lost. Try resetting the IPmodem. If the error persists for more than four hours, contact your ISP, as this could indicate a general network problem.
  • Z
    Zachary LaneSep 2, 2025
    What to do if Newtec TP210 Modem shows 'TCP acceleration service failed'?
    • J
      Joshua RussellSep 2, 2025
      If the Newtec Modem web interface displays 'TCP acceleration service failed' and the Warning LED and RX LED are on, it indicates an error in the TCP acceleration service. To resolve this, reset the IPmodem. If the error persists for more than four hours, contact your ISP.
  • J
    Jennifer LaraSep 4, 2025
    What to do if Newtec TP210 Modem shows 'Terminal specific forward carrier lookup is ongoing'?
    • W
      Whitney GreenSep 4, 2025
      If the Newtec Modem web interface displays 'Terminal specific forward carrier lookup is ongoing' and the Warning LED and RX LED are on, give it 10 minutes to disappear. If the message remains, reset the modem. If the error continues after several hours, contact your ISP to report the problem and check if your IPmodem is provisioned in the network.
  • M
    Mark HubbardSep 7, 2025
    What to do if Newtec TP210 Modem shows 'Network Layer configuration failed'?
    • M
      Michelle LeonardSep 7, 2025
      If the Newtec Modem web interface displays 'Network Layer configuration failed' and the Warning LED and RX LED are on, it indicates an error during the configuration of the network layers after a valid satellite network login. Try resetting the IPmodem. If the error persists, contact your ISP and provide them with any additional error information displayed.
  • D
    davidmeadowsSep 9, 2025
    What to do if Newtec TP210 shows 'Network login failed'?
    • E
      elizabeth83Sep 10, 2025
      If the Newtec Modem web interface displays 'Network login failed' and the Warning LED and RX LED are on, verify that the TX cable is correctly connected. If the error persists after several hours with a correctly connected TX cable, contact your ISP to report the problem and check if your IPmodem is provisioned in the network.

Summary

About the Manual

Cautions and Symbols

Describes symbols used in the manual and their meanings.

Version History and Applicability

Lists document versions, release dates, and software applicability.

Related Documentation

Product Range

Lists the available satellite terminal models and their antenna sizes.

Important Safety Precautions

Warnings

Lists critical warnings for safety, potential hazards, and warranty implications.

Cautions

Notices

1 Introduction

1.1 About the Satellite Terminal

Provides a description of the satellite terminal and its capabilities.

1.2 Installation Tasks

Outlines the necessary installation tasks and refers to the setup manual.

2 Satellite Terminal Components

2.1 The IPmodem

Details the IPmodem component, including its front and back panels.

2.2 The Pointing Tool

Describes the functionality and parts of the antenna pointing device.

2.3 Cables

Details the types of cables included with the satellite terminal system.

2.4 The iLNB

Describes the iLNB (Interactive Low Noise Block-down converter) component.

2.5 The Antenna

Provides information about the satellite antenna and its assembly.

3 Terminal Web Interface

3.1 Prepare the Settings of Your Computer

Steps to configure your computer's network settings for the terminal.

3.2 How to Access the Terminal Web Interface?

Instructions on accessing the terminal's web interface.

3.3 Overview Web Interface

General overview of the web interface layout and structure.

3.4 Reboot the IPmodem

Procedure for rebooting the IPmodem via the web interface.

3.5 LEDs in the Status Bar

Explanation of the status LEDs on the IPmodem and their meanings.

3.6 Status Page

Details on the different sections of the terminal's status page.

3.7 Configuration

Introduction to the configuration settings for the terminal.

3.8 Device

Information related to the device's software and hardware.

3.9 Antenna Pointing

Information and status regarding the antenna pointing procedure.

3.10 Test

Overview of the diagnostic tests that can be performed on the terminal.

4 Appendix A - Local Network Configuration

4.1 Connect a Single Computer to the IPmodem

Guide for connecting a single computer to the IPmodem.

4.2 Connect a LAN to the IPmodem

Instructions for connecting a local area network (LAN) to the IPmodem.

5 Appendix B - Setting and Changing Your IP Settings

5.1 Windows 7

Procedure to set or change IP settings on Windows 7.

5.2 Windows Vista

Procedure to set or change IP settings on Windows Vista.

5.3 Windows XP

Procedure to set or change IP settings on Windows XP.

5.4 Mac OS X

Procedure to set or change IP settings on Mac OS X.

6 Appendix C - Troubleshooting Guide

7 Appendix D - Acronyms

8 Appendix E - Licenses

9 Appendix F - Terminal Specifications

9.1 IPmodem (indoor unit)

Technical specifications for the IPmodem indoor unit.

9.2 Coaxial cable

Electrical and environmental specifications for the coaxial cable.

9.3 iLNB (outdoor unit)

Performance and environmental specifications for the iLNB outdoor unit.

9.4 Antenna

Environmental and dimensional specifications for the satellite antenna.
