Newtec TP210 - 9.2 Coaxial cable; 9.3 iLNB (outdoor unit)

Appendix F – Terminal SpecificatIons User Manual for the Satellite Terminal
version 3.0
52
 Screening attenuation : > 85 dB up to 2150 MHz, > 75 dB up to 3000 MHz
 DC-Resistance : < 3 Ohm (inner+outer)
 Compliant to standards : EN50117-2-4 and EN501117-2-5 (up to 3000 MHz)
Environment

Ambient Temperature : -40 to +80 °C (operating & storage)
 Minimum Installation Temperature : -5 °C
 Relative Humidity : 0 ~ 100 %
 Weather Protection : IP67 – incl. Industrial & Coastal
 Solar Radiation : 1120 W/m²
9.3 iLNB (outdoor unit)
Performance
 Receive characteristics
 Gain : 57 to 70 dB ± 0.5 dB / 10 °C
 Spectrum conversion : non-inverted
 Transmit characteristics
 Output power : + 27 dBm typ. for 500mW version (NTC/2530)
+ 29 dBm typ. for 800mW version (NTC/2532)
 Power stability : ± 1.5 dB / 90 °C
 Spectrum conversion : non-inverted
Interface

RF in (receive)
 Frequency : 10.7 – 12.75 GHz
 Polarisation : physical mounting
 RF out (transmit)
 Frequency : 13.75 – 14.5 GHz (Ku-band)
 Polarisation : linear and orthogonal to Rx
Environment

Ambient Temperature : -30 to +60 °C
 Weather Protection : IP67
 Humidity : 0 ~ 100% (condensing)
 Solar Radiation : 500 W/m² maximum
 Rain : < 40 mm/h
 Wind Load : < 80 km/h no deterioration
 Wind Load (survival) : < 180 km/h
