Newtec TP210 - 9.4 Antenna

Appendix F – Terminal SpecificatIons User Manual for the Satellite Terminal
version 3.0
53
9.4 Antenna
Environment
 Ambient Temperature : -30 to +60 °C
 Weather protection : incl. Industrial & coastal
 Relative Humidity : 0 ~100 %
 Solar Radiation : 1120 W/m²
 Wind Load (operating
1
) : < 80 km/h (< 0.22° dev.TX)
 Wind Load (survival
2
) : < 180 km/h
Dimensions
 TP210 satellite terminal with 75cm antenna
- Reflector Height : 810 mm
- Reflector Width : 750 mm
- Aperture : 750 mm
- Feed clamp : 40 mm diameter
- Elevation range : 0 – 90 deg
- Azimuth range : 0 – 360 deg
- Mast dimensions : 45 – 70 mm (60 – 70 mm recommended)
- Colour : light grey – RAL 7037
- Weight : 10 kg
 TP211 satellite terminal with 1m antenna
- Reflector Height : 1127 mm
- Reflector Width : 1000 mm
- Aperture : 1000 mm
- Feed clamp : 40 mm diameter
- Elevation range : 13 – 90 deg
- Azimuth range : 0 – 360 deg
- Mast dimensions : 65 – 76 mm
- Colour : light grey – RAL 7037
- Weight : 17 kg
1
Operating: antenna remains operational with a maximum pointing degradation as indicated.
2
Survival: the antenna will be degraded permanently, however no parts of the antenna will get
loose.
