Satellite Terminal Components
User Manual for the Satellite Terminal
version 3.0
7
2.5 The antenna
The antenna and masthead are developed for easy assembly and installation with
integrated fine-adjustment mechanism.
The antenna is delivered including the masthead, excluding the antenna mast
(pole)/mount or wall-mount.
Please refer to the Point&Play Setup Manual for the antenna pole
requirements.
Figure 7 – Antenna
