Terminal Web Interface
User Manual for the Satellite Terminal
version 3.0
18
Click on in the Web Interface > View Configuration Ethernet
interface (Figure 17) to change the Ethernet Settings;
Edit the parameters to be changed;
Click on
in the Web Interface > Edit Configuration Ethernet interface
(Figure 18) to save the new settings.
The Ethernet interface configuration is now saved!
3.7.2 Satellite Interface
The satellite interface settings are predefined in factory. These
settings may only be changed upon advice of your internet service
provider!
3.7.2.1 Introduction
This section describes the interface settings between the terminal and the satellite.
Every satellite interface setting consists of:
Initial Receive Carrier
This is the initial receive carrier via which the IPmodem will try to gain access to the
network.
Pointing Carrier
This carrier is needed to enable antenna pointing via the Point&Play mechanism.
When two different pointing carriers are assigned to the terminal, the installer can
perform his pointing on two different pointing carriers. At least one pointing carrier
must be enabled.
3.7.2.2 View the Satellite Interface Configuration
Maximum two initial receive carrie
r settings and pointing carrier settings can be
assigned and displayed. Only the settings that are enabled are displayed. How to
change the satellite interface configuration is described in section
3.7.2.4.
If two settings for a carrie
r are enabled and displayed, the preferred initial receive
carrier is marked by
.
If two settings for a carrie
r are enabled and displayed, the default pointing carrier is
marked by
The final selection of the pointing carrier that is used for pointing is
done in the Status Page as shown in Figure 14, where the non-default pointing
carrier can be selected.
In the example of Figure 19, two initial receive carriers and two pointing carriers are
enabled. Initial Receive Carrier 2 is marked as preferred, and Pointing Carrier 1 is
set as default.
