3.5.2 Satellite LED
The Satellite LED gives the general status of the Satellite connection to the
IPmodem.
LED colour code Description
Red No connectivity, no valid signal received.
Yellow
A valid signal was received. The terminal is busy logging in
on the satellite network.
Green
The system is operational and the user is logged in on the
satellite network.
Table 6 - Status LEDs > Satellite
3.5.3 Software LED
The Software LED gives the general status of the installed software or the updates.
LED colour code Description
Red
The terminal has a newer software version than the running
software version, and
The newer software version was not selected because the
software validation process failed.
See Appendix C – Troubleshooting Guide for possible
action
s and follow-up.
Yellow
The terminal is retrieving new software via satellite. This can
take up to 10 minutes.
Green
No problem. The terminal is running with the latest software
version.
Table 7 - Status LEDs > Software
3.6 Status Page
3.6.1 Introduction
In normal operation, when the terminal is pointed and active, there are two parts to
the Status Page as shown in Figure 12, which are described in more detail in the
following sections:
Overview;
This part gives an overview of the IPmodem, demodulator and software state.
Interface Statistics;
This part gives an overview of the IPmodem statistics.
